Technical Data Sheet
Key Features
· Absolute Directional Stability: The 'X' disc arrangement prevents sideways drift, enabling the machine to travel in a perfectly straight line without the tractor needing to correct its path. This drastically reduces fuel consumption.
· Exclusive Dual Accumulator: It is unique on the market thanks to its two separate hydro-pneumatic accumulators (one per row), which allow for independent control of depth and stability. This ensures a clean finish, even in mixed soil conditions.
· Hydropneumatic No-Stop System: Each disc operates independently and is protected. In the event of stones or obstacles, the individual module instantly lifts and repositions itself without forcing the operator to stop.
· Anti-Clogging Efficiency: Thanks to the generous spacing of 29 cm between the discs, the machine can quickly discharge soil and large amounts of crop residue, such as maize, thereby preventing operational blockages.
· Simplified Logistics: Models up to the RAPID-28 are fitted with a 2.50-metre hydraulic folding mechanism that enables them to be transported quickly and safely on the road without the need for special permits.
· Working Depth: It is precisely adjustable down to 10 cm, making it ideal for mechanical weed control and seedbed preparation.
· Performance: Tests have demonstrated that the DIR RAPID's combined shredding and levelling action reduces working times, making it an 'all-in-one' solution for farm optimisation.
| Model | Folding (TIPO) | Units (N) | Overall Width (CM) | Working width (CM) | Weight (KG) | Power (HP) |
|---|---|---|---|---|---|---|
| RAPID-18 | 18 | 278 | 278 | 1050 | 90-100 | |
| RAPID-20 | IDRAULICO | 20 (16+4) | 248 | 300 | 1270 | 90-100 |
| RAPID-20U | 20 | 248 | 300 | 1150 | 90-100 | |
| RAPID-22U | 22 | 330 | 330 | 1250 | 90-100 | |
| RAPID-24 | IDRAULICO | 24 (16+8) | 248 | 360 | 1530 | 110-130 |
| RAPID-28 | IDRAULICO | 28(16+12) | 248 | 390 | 1750 | 140-160 |
| RAPID-30 | IDRAULICO | 30(18+12) | 278 | 420 | 1850 | 160-200 |
| RAPID-34 | IDRAULICO | 34 (18+16) | 278 | 480 | 2100 | 180-200 |
| RAPID-32S | IDRAULICO | 32 (20+12) | 310 | 450 | 1950 | 180-200 |
| RAPID-36S | IDRAULICO | 36 (20+16) | 310 | 510 | 2200 | 200-250 |
| Hydraulic locking mechanism for locking pins |
